Black Omron Power Supply Unit CPU Controllers 24V DC CS1D-PD025

Brand Name : Omron

Model Number : CS1D-PD025

Place of Origin : China/Japan

MOQ : 1/pc

Price : $50-500

Supply Ability : 10pc/per week

Packaging Details : Carton packaging

Payment Terms : T/T, western union

Type : Controllers

Condition : 100% Original

Color : Black

Delivery Time : Within 3 Working Days

Package : 100% Original Package

Warranty : 1 Year

Power supply voltage : 24VDC

Power consumption : 60 W max

Port : Selectable

Contact Now

Omron Power Supply Unit CS1D-PD025

Product Details

  • Omron CS1D Series CPU Backplane

  • Flexible configuration to suit your system requirements
    Choose the level of redundancy needed
    Supports a variety of network configurations


    Easy installation and operation of reliable systems
    Easy duplexing of CPU units
    Easy duplexing of communications units
    Easy duplexing of power supply units
    Replace units during power supply
    Remove or add units without using a programming device
    Automatic recovery to duplex operation


    Improve development productivity
    CPU unit with a large program capacity of 400K steps for structured and modular programming
    Improve development productivity by reusing and sharing programs
    Reuse software assets
    Units common to all CS Series
    Verify errors on physical devices

Specifications

Item CS1D-PD025
Power supply voltage 24 V DC
Operating voltage range 19.2 to 28.8 V DC
Power consumption 60 W max
Inrush current 30 A max.
Power supply output capacity 5 V DC, 5.3 A (including the CPU
Unit power supply)
26 V DC, 1.3 A
Total: 40 W
Power supply output terminal Not provided.
RUN output *1 Not provided.
Insulation resistance 20 M min. (at 500 V DC) between DC external and GR terminals
Dielectric strength Between DC external and GR terminals *2: 1,000 V AC 50/60 Hz for 1 min Leakage current: 10 mA max.
Noise immunity 2 kV on power supply line (conforming to IEC61000-4-4)
Vibration resistance 10 to 57 Hz, 0.075-mm amplitude, 57 to 150 Hz, acceleration: 9.8 m/s2 in X, Y, and Z directions for 80 minutes (Time coefficient: 8 minutes × coefficient factor 10 = total time 80 minutes) (When mounted on a DIN Track: 2 to 55 Hz, acceleration of 2.9 m/s2 in X, Y, and Z directions for 20 minutes) (conforming to IEC60068-2-6)
Shock resistance 147 m/s2 3 times each in X, Y, and Z directions (conforming to IEC60068-2-27)
